1.27 Header BUS Socket SMD for M5StampS3 (10 sets)

M5Stack 1.27 Header BUS Socket SMD for M5StampS3 (10 sets)

5,45 €

Description

The Stamp-S3 socket kit is a 1.27mm surface-mount socket set for integrating a Stamp-S3 module into custom PCB designs. It combines 17-pin and 11-pin SMD sockets so a board can provide the matching mechanical and electrical interface for compact embedded builds.

This Stamp-S3 socket kit is useful when a project needs repeatable module mounting, cleaner board assembly, or easier replacement during testing. The low 4.6mm socket height keeps the finished board compact while still supporting practical prototype and small-batch PCB work.

Features

  • 1.27mm pitch surface-mount socket set for Stamp-S3 PCB integration.
  • Includes matched 17-pin and 11-pin sockets for the Stamp-S3 module layout.
  • 4.6mm socket height for compact embedded hardware designs.
  • Designed for PCB DIY, prototype boards, and custom expansion hardware.
  • Stamp-S3 socket kit package provides ten complete socket sets.

Specifications

Type Surface-mount socket set for Stamp-S3 PCB designs
Socket type 17Pin / 11Pin
Pitch 1.27 mm
Socket height 4.6 mm
Operating temperature -40°C to 105°C
Soldering temperature 230°C for 30-60 seconds / 260°C for 10 seconds
Socket dimensions 22 x 4.6 x 3.5 mm for 17P, 14 x 4.6 x 3.5 mm for 11P
Net weight 0.4 g for 17P / 0.1 g for 11P
Package size 136 x 92 x 13 mm
Set weight 6.7 g
Package weight 8.7 g

Applications

  • PCB DIY projects using the Stamp-S3 module.
  • Custom controller boards, compact IoT nodes, and embedded expansion boards.
  • Prototype layouts that need repeatable module installation during testing.
  • Small-batch boards where the Stamp-S3 socket kit helps standardize assembly.

Product List

  • 10 x Surface-mount sockets (1.27mm-17Pin)
  • 10 x Surface-mount sockets (1.27mm-11Pin)

Other Content

Before soldering, verify the 17-pin and 11-pin socket orientation against the PCB footprint. Use the listed soldering temperature limits and inspect alignment after placement, especially on compact boards where the module position affects enclosure clearance.
